Dimensions: 77.5mm x 66mm x 45mm
Weight: 75g
Voltage: 3.3-5 VDC
Current: 200mA
Performance Characteristics
Image (Pixels): 640 pixels (H)x 480 pixels (V)
Light Source: Illumination:6500K LED
Field of View: 72° (H) x 64° (V)
Roll / Pitch / Yaw: 360°, ±65°, ±60°
Print Contrast: 20% minimum reflective difference
Interfaces Supported: USB, RS232
Motion Tolerances: >2m/s
Symbology Decode Capability
1-D: UPC, EAN, Code 128, Code 39, Code 93, Code 11, Matrix 2 of 5, Codabar Interleaved 2 of 5, Mis Plessey, GSI DataBar, China Postal,
Korean Postal
, etc
2-D: PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec
Hanxin, etc.
Minimum Resolution: ≥3.9 mil
User Environment
Operating Temperature: -40°C to 70°C
Storage Temperature: -50°C to 85°C
Humidity 0% to 95% relative humidity,non-condensing
Shock Specifications Designed to withstand 1.5m(5′) drops
Ambient Light Immunity 0-100,000 Lux.
Decode Ranges
6.88 mil (PDF417) 0mm-50mm
10 mil (Data Matrix) 0mm-50mm
13 mil (UPCA) 5mm-110mm
20 mil (QR) 0mm-100mm
Certificates CE,ROHS,FC
