1 Input Voltage DC 5V ±5%
2 Power 258mw(work); 100nw(task state); 380nw(MAX. Peak)
3Source
host machine supply keyboard interface; RS232 external or host
machine
4 Current 50ma(work); 30mw(task state); 100mw(Max. Peak)
5 Light Source Visible laser 650nm
6 Laser Grade State secondary laser safety standard
7 Depth of Field 2-9cm(0.1mm bar width); 3-40cm(0.3mm bar width)
8 Scan Width 5cm ~ 30cm
9 Decode Speed 120 times/s
10 Readable bar width Min. 0.1mm(4 miles)
11Decode capacity
UPC-A, UPC-E, EAN-13, ISBN/ISSN, code 39, codabar, interleaved
25 code,Matrix 25 code, code 128, code11, MSI/PIESSEY, UK/PLES
SEY, UCC/EAN128 code, China post code Etc.
12 Notice Method Indicator Led, Buzzer
13System Interface
IBM PS/2 keyboard, IBM PC/XT/AT, RS-232 serial interface;
Standard 2.0USB port
14Trigger Method
Manual operation; continuous scan automatically; infrared scanning
automatically, holder scanning automatically(selectable)
15 Dimension 9.80cm×6.80cm×15.80cm(L*W*H)
16 Weight 135G
17 Electric Cable Standard Straight line 2m
18 Interface Type RJ-45
19 Jacket Material ABS+PC+PVC
20 Working Temperature -10°C~60°C
21 Storage temperature -20°C~60°C
22 Operation humidity 0~95%
23 Shock resistance 1.5m free-fall test
24 Language Multi-language
